Granite Block Cutter
Granite Block Cutter
Granite Block Cutter is best suited for cutting of granite blocks.circular disk type wheel cutting machine with drive pulley and block carrying trolley with motorized movement .The trolley moves on machined rail lines with automatic feet system.
TECHNICAL SPECIFICATION
| Beam | 1 NO'S | 18ft | 20ft |
| up Down Motor | 1 NO'S | 3 HP | 3 HP |
| A.C Motor | 1 No'S | 3 HP | 3 HP |
| Trolley Motor | 1 NO'S | 2 HP | 2 HP |
| Master Trolley | 1 NO'S | ||
| Loading Trolley | 2 NO'S | Standard | Standard |
| V Shape Rail Lines | 2 NO'S | 12ft | 12ft |
| Electrical Control panel | 1 NO'S | ||
| Main Motor | 1 NO'S | 30HP/960RPM | 40HP/960RPM |
